Descripción del producto:

YBLMy type high pressure cylinder pulse dust collector use large tangential centrifugal air intake ,cylindrical body box, long conical bucket feeding, equipped with cylindrical filter bag and unique pulse injection device , it possessed with low equipment resistance ,light filter bag load , large processing air volume,high dust removal efficiency,compact structure and other advantages.
This machine is suitable for single or centralized dust removal and dust removal in pneumatic conveying in food and feed industry ,and is also used on dust recovery and filtration in other industries.

Características:

1.flexible process layout, cover a little area.
2.Una válvula solenoide puede controlar varias bolsas de tela.
3. Alta eficiencia de eliminación de polvo, selección multifunción de bolsa de tela para eliminación de polvo: ultrafina, resistente a la temperatura, resistente a la humedad, antiestática, etc.
4.The special circular air bag with straight solenoid valve reduce the damage of the solenoid valve diaphragm, stable and reliable work.
5.The new practical patent technology, original structure, compact process.

Información del modelo:

Modelo	TBLMy9	TBLMy12	TBLMy15	TBLMy18	TBLMy26	TBLMy39	TBLMy52	TBLMy72	TBLMy78
Bag (pc)	9	12	15	18	26	39	52	72	78
Filtering Area (m²)	3.7/5.5/7.4	5/7.3/9.9	6.2/9.2/12.3	7.4/11/14.8	10.7/15.9/21.3	16/23.8/32	21.3/31.8/42.7	29.4/44.1/58.8	32/47.6/64
Caudal de aire (m³/h)	660 1300 ~	900 1800 ~	1100 2200 ~	1300 2660 ~	2000 3800 ~	2900 5800 ~	3800 7700 ~	5300 10600 ~	5800 11500 ~
Presión de aire comprimido (Mpa)	0.5 0.7 ~
Ancho de pulso (s)	0.01 0.5 ~
Pulse Interval (s)	3 90 ~
Dedusting Efficiency %	≥ 99.8
