Home > Products > Conveying equipment > TLSU / TLSG series screw conveyor
Suitable for conveying various raw materials, semi-finished grain, feed, and other small granular or powdery materials in industries such as grain depots, ports, grain processing plants, light industry, pharmaceuticals, brewing, etc. It can be used for horizontal or inclined conveying.
1.Two conveying types (shafted, shaftless) to adapt to different material characteristics;
2. Adopts internationally advanced reducer and hydraulic coupling transmission technology;
3. Variable-pitch blades ensure smooth material feeding;
4. Equipped with anti-blocking alarm function at the outlet;
5. Provided with quick-opening access doors for easy cleaning;
6. Equipped with stall alarm function;
7. Barrel is fitted with ventilation devices to release air pressure;
8. Chain drive and direct drive options available to meet different production scenarios;
9. Optional feeding methods to satisfy diverse production requirements.
| Model | Max Power(KW) | Capacity(m³/H) | Rotating Speed(rpm) |
| TLSU/TLSG 10 | ≤3 | 1-3 | ≤136 |
| TLSU/TLSG 16 | ≤5.5 | 10-15 | ≤136 |
| TLSU/TLSG 20 | ≤7.5 | 20-30 | ≤136 |
| TLSU/TLSG 25 | ≤11 | 35-60 | ≤136 |
| TLSU/TLSG 28 | ≤11 | 50-80 | ≤136 |
| TLSU/TLSG 32 | ≤15 | 70-110 | ≤120 |
| TLSU/TLSG 40 | ≤15 | 110-180 | ≤110 |
