1. Material: X46Cr13 /4Cr13(stainless steel),
20MnCr5/20CrMnTi (alloy steel)
customized
2. Hardness: HRC54-60.
3. Diameter: 1.0mm up to 28mm
4. Pellet die type: Ring Die or Flat Die
5. Outer diameter: Outer diameter up to 1800mm
6. Pellet Die model we can customize: CPM, Buhler, CPP, OGM, Zhengchang(SZLH/MZLH), etc. We can customize for you according to your drawing.
| Model | (External size x Internal size x Total width x Width of working surface-mm） | Diameter |
| SZLH320 | 432*320*130*89 | φ1-φ8 |
| SZLH350 | 500*350*180*100 | |
| SZLH400 | 558*400*200*120 | |
| SZLH420 | 580*420*195*120 | |
| SZLH420D | 580*420*213*138 | |
| SZLH508 | 660*508.8*238*155 | φ2-φ12 |
| SZLH558 | 774.7*572*324.46*208.6 | |
| SZLH678 | 910*673*325*180 | |
| SZLH768 | 970*762*370*210 |
