Quick action, reliable and stable work, easy operation;
Control the gate opening by adjusting the position of magnet switch, then to control the flow of material.
Pneumatic control , clean and easy operation.
Inlet and outlet can be customized
| Model | Air cylinder dia. | Work pressure | Inlet and outlet size (mm) |
| (mm) | (MPa) | ||
| TZMQ25x25 | 50 | 0.4-0.8 | 250x250 |
| TZMQ32x32 | 50 | 0.4-0.8 | 320x320 |
| TZMQ40x40 | 63 | 0.4-0.8 | 400x400 |
| TZMQ50x50 | 80 | 0.4-0.8 | 500x500 |
| TZMQ60x25 | 80 | 0.4-0.8 | 600x250 |
| TZMQ60x32 | 100 | 0.4-0.8 | 600x320 |
| TZMQ70x70 | 100 | 0.4-0.8 | 700x700 |
| TZMQ80x20 | 80 | 0.4-0.8 | 800x200 |
| TZMQ80x25 | 80 | 0.4-0.8 | 800x250 |
| TZMQ80x32 | 80 | 0.4-0.8 | 800x320 |
